Manufacturer Part Number: | PQA50-D48-S15-DH |
---|---|
Manufacturer: | CUI Inc. |
Product Category: | DC DC Converters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | DC/DC CONVERTER 15V 50W |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PQA50-D48-S15-DH Datasheet |
Internal Part Number | 898-PQA50-D48-S15-DH | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Thermal Management of Power Supplies | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | CUI Inc. | |
Series | PQA50-D | |
Packaging | Bulk | |
Part Status | Active | |
Type | Isolated Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 36V | |
Voltage - Input (Max) | 75V | |
Voltage - Output 1 | 15V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 3.333A | |
Power (Watts) - Manufacture Series | 50W | |
Voltage - Isolation | 1.5kV (1500V) | |
Applications | ITE (Commercial) | |
Features | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | |
Mounting Type | Through Hole | |
Package / Case | 6-DIP Module | |
Size / Dimension | 2.00" L x 1.00" W x 0.64" H (50.8mm x 25.4mm x 16.3mm) | |
Operating Temperature | -40°C ~ 85°C | |
Efficiency | 93% | |
Power (Watts) - Max | 50W | |
Standard Package | 42 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | PQA50-D48-S15-DH | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PQA50-D48-S15-DH is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of PQA50-D48-S15-DH is new and unused, you can buy PQA50-D48-S15-DH CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PQA50-D48-S15-DH.
