| Manufacturer Part Number: | PPC8309VMAGDCA |
|---|---|
| Manufacturer: | NXP Semiconductors |
| Product Category: | Embedded - Microprocessors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | PowerPC e300c3 Microprocessor IC MPC83xx 1 Core, 32-Bit 400MHz 489-PBGA (19x19) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PPC8309VMAGDCA Datasheet |
| Internal Part Number | 898-PPC8309VMAGDCA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | 8306/09 Families Datasheet Update 11/Jul/2013 Errata Update 03/Sep/2015 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microprocessors | |
| Manufacturer | Freescale Semiconductor - NXP | |
| Series | MPC83xx | |
| Packaging | Tray | |
| Part Status | Obsolete | |
| Core Processor | PowerPC e300c3 | |
| Number of Cores/Bus Width | 1 Core, 32-Bit | |
| Speed | 400MHz | |
| Co-Processors/DSP | Communications; QUICC Engine | |
| RAM Controllers | DDR2 | |
| Graphics Acceleration | No | |
| Display & Interface Controllers | - | |
| Ethernet | 10/100 Mbps (3) | |
| SATA | - | |
| USB | USB 2.0 (1) | |
| Voltage - I/O | 1.8V, 3.3V | |
| Operating Temperature | 0°C ~ 105°C (TA) | |
| Security Features | - | |
| Package / Case | 489-LFBGA | |
| Supplier Device Package | 489-PBGA (19x19) | |
| Additional Interfaces | CAN, DUART, I²C, MMC/SD, PCI, SPI, TDM | |
| Standard Package | 84 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PPC8309VMAGDCA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PPC8309VMAGDCA is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of PPC8309VMAGDCA is new and unused, you can buy PPC8309VMAGDCA NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PPC8309VMAGDCA.
