Manufacturer Part Number: | PP2-1U7-2B2 |
---|---|
Manufacturer: | E-Switch |
Product Category: | Snap Action, Limit Switches |
Available Quantity: | 11203 Pieces |
Unit Price: | Quote by Email |
Description: | SWITCH DETECTOR DPDT 16A 125V |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PP2-1U7-2B2 Datasheet |
Internal Part Number | 898-PP2-1U7-2B2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Power Switch Overview | |
RoHS Information | Switches RoHS Certof Compliance | |
Online Catalog | PP2 Series | |
Category | Switches | |
Family | Snap Action, Limit Switches | |
Manufacturer | E-Switch | |
Series | PP2 | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | DPDT | |
Switch Function | On-On-Mom | |
Current Rating | 16A (AC) | |
Voltage Rating - AC | 125V | |
Voltage Rating - DC | - | |
Actuator Type | Push-Pull Plunger | |
Mounting Type | Panel Mount, Snap-In | |
Termination Style | Quick Connect - 0.187" (4.7mm) | |
Ingress Protection | - | |
Features | White Actuator | |
Operating Force, Torque | 330gf | |
Release Force | - | |
Pretravel | - | |
Differential Travel | - | |
Overtravel | - | |
Operating Position | 0.610" (15.5mm) | |
Mechanical Life | 50,000 Cycles | |
Electrical Life | 6,000 Cycles | |
Operating Temperature | 0°C ~ 85°C | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | PP2-1U7-2B2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PP2-1U7-2B2 is in stock for immediate shipping now. We are the distributor of E-Switch all series components. The condition of PP2-1U7-2B2 is new and unused, you can buy PP2-1U7-2B2 E-Switch with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PP2-1U7-2B2.
