| Manufacturer Part Number: | PM30-12T05-12 |
|---|---|
| Manufacturer: | TDK-Lambda Americas Inc. |
| Product Category: | DC DC Converters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | POWER SUPPLY |
| Lead Free Status / RoHS Status: | Lead free by exemption / RoHS compliant by exemption |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PM30-12T05-12 Datasheet |
| Internal Part Number | 898-PM30-12T05-12 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Manufacturer | TDK-Lambda Americas Inc. | |
| Series | PM30 | |
| Packaging | - | |
| Part Status | Obsolete | |
| Type | Isolated Module | |
| Number of Outputs | 3 | |
| Voltage - Input (Min) | 9V | |
| Voltage - Input (Max) | 18V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | 12V | |
| Voltage - Output 3 | -12V | |
| Current - Output (Max) | 5A, 1A, 1A | |
| Power (Watts) - Manufacture Series | 30W | |
| Voltage - Isolation | 700V | |
| Applications | ITE (Commercial) | |
| Features | - | |
| Mounting Type | Through Hole | |
| Package / Case | 9-DIP Module (8 Leads) | |
| Size / Dimension | 3.00" L x 2.50" W x 0.33" H (76.2mm x 63.5mm x 8.4mm) | |
| Operating Temperature | -40°C ~ 50°C | |
| Efficiency | - | |
| Power (Watts) - Max | 30W | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PM30-12T05-12 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PM30-12T05-12 is in stock for immediate shipping now. We are the distributor of TDK-Lambda Americas Inc. all series components. The condition of PM30-12T05-12 is new and unused, you can buy PM30-12T05-12 TDK-Lambda Americas Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PM30-12T05-12.
