Manufacturer Part Number: | PM-5R0H105-R |
---|---|
Manufacturer: | Eaton |
Product Category: | Electric Double Layer Capacitors, Supercaps |
Available Quantity: | 9334 Pieces |
Unit Price: | Quote by Email |
Description: | 1F Supercap 5V Radial, Can, Horizontal 200 mOhm 1000 Hrs @ 60°C 0.866" L x 0.681" W (22.00mm x 17.30mm) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PM-5R0H105-R Datasheet |
Internal Part Number | 898-PM-5R0H105-R | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | PowerStor Supercapacitors PowerStor Brand Supercapacitors-Size and Selection | |
MSDS Material Safety Datasheet | PM Series MSDS | |
Featured Product | PM Series 5.0 Volt Supercapacitors | |
PCN Design/Specification | PA,PB,PHB,PHV,PM Series UV Epoxy 01/May/2014 PA,PB,PHB,PHV,PM Series 01/May/2014 | |
PCN Assembly/Origin | PowerStor® Shipping Method 01/Jan/2013 | |
Online Catalog | PowerStor, Radial Can Series | |
Category | Capacitors | |
Family | Electric Double Layer Capacitors, Supercaps | |
Manufacturer | Eaton | |
Series | PowerStor PM | |
Packaging | Bulk | |
Part Status | Active | |
Capacitance | 1F | |
Tolerance | -20%, +80% | |
Voltage - Rated | 5V | |
ESR (Equivalent Series Resistance) | 200 mOhm | |
Lifetime @ Temp. | 1000 Hrs @ 60°C | |
Termination | Through Hole | |
Mounting Type | Through Hole | |
Package / Case | Radial, Can, Horizontal | |
Lead Spacing | 0.465" (11.80mm) | |
Size / Dimension | 0.866" L x 0.681" W (22.00mm x 17.30mm) | |
Height - Seated (Max) | 0.354" (9.00mm) | |
Operating Temperature | -40°C ~ 60°C | |
Standard Package | 100 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | PM-5R0H105-R | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PM-5R0H105-R is in stock for immediate shipping now. We are the distributor of Eaton all series components. The condition of PM-5R0H105-R is new and unused, you can buy PM-5R0H105-R Eaton with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PM-5R0H105-R.
