Manufacturer Part Number: | PK25-D5-S12 |
---|---|
Manufacturer: | CUI Inc. |
Product Category: | DC DC Converters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | DC/DC CONVERTER 12V 20W |
Lead Free Status / RoHS Status: | Vendor undefined / Vendor undefined |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PK25-D5-S12 Datasheet |
Internal Part Number | 898-PK25-D5-S12 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | PK25-D5-S12 Cert of Compliance | |
PCN Obsolescence/ EOL | PK15, PK25 Series 26/Nov/2012 | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | CUI Inc. | |
Series | PK25 | |
Packaging | Bulk | |
Part Status | Obsolete | |
Type | Isolated Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 4.5V | |
Voltage - Input (Max) | 9V | |
Voltage - Output 1 | 12V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 1.7A | |
Power (Watts) - Manufacture Series | 25W | |
Voltage - Isolation | 500V | |
Applications | ITE (Commercial) | |
Features | Remote On/Off, OCP, OVP | |
Mounting Type | Through Hole | |
Package / Case | 7-DIP Module | |
Size / Dimension | 2.56" L x 2.00" W x 0.38" H (65.0mm x 50.8mm x 9.7mm) | |
Operating Temperature | -20°C ~ 71°C | |
Efficiency | 77% | |
Power (Watts) - Max | 20.4W | |
Standard Package | 60 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | PK25-D5-S12 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PK25-D5-S12 is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of PK25-D5-S12 is new and unused, you can buy PK25-D5-S12 CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PK25-D5-S12.
