| Manufacturer Part Number: | PJRXS24AD |
|---|---|
| Manufacturer: | Crouzet USA |
| Product Category: | Power Relays, Over 2 Amps |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Impulse Relay DPDT (2 Form C) 24VAC/DC Coil Socketable |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PJRXS24AD Datasheet |
| Internal Part Number | 898-PJRXS24AD | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| Online Catalog | JRS Series | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Manufacturer | Crouzet USA | |
| Series | JRS | |
| Packaging | Bulk | |
| Part Status | Active | |
| Relay Type | Impulse | |
| Coil Type | Latching, Single Coil | |
| Coil Current | - | |
| Coil Voltage | 24VAC/DC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 10A | |
| Switching Voltage | 250VAC, 250VDC - Max | |
| Turn On Voltage (Max) | - | |
| Turn Off Voltage (Min) | - | |
| Operate Time | - | |
| Release Time | - | |
| Features | LED Indicator | |
| Mounting Type | Socketable | |
| Termination Style | Plug In, 8 Pin (Octal) | |
| Contact Material | Silver Cadmium Oxide (AgCdO) | |
| Coil Power | - | |
| Coil Resistance | - | |
| Operating Temperature | -10°C ~ 60°C | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PJRXS24AD | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PJRXS24AD is in stock for immediate shipping now. We are the distributor of Crouzet USA all series components. The condition of PJRXS24AD is new and unused, you can buy PJRXS24AD Crouzet USA with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PJRXS24AD.
