| Manufacturer Part Number: | PJ-066B |
|---|---|
| Manufacturer: | CUI Inc. |
| Product Category: | Barrel - Power Connectors |
| Available Quantity: | 15739 Pieces |
| Unit Price: | Quote by Email |
| Description: | CONN JACK 2.5X5.5MM R/A PWR PNL |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PJ-066B Datasheet |
| Internal Part Number | 898-PJ-066B | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | PJ-066B Cert of Compliance | |
| 3D Model | PJ-066B | |
| Online Catalog | CUI Inc | |
| Category | Connectors, Interconnects | |
| Family | Barrel - Power Connectors | |
| Manufacturer | CUI Inc. | |
| Series | - | |
| Packaging | Bulk | |
| Part Status | Active | |
| Connector Type | Jack | |
| Gender | Male | |
| Industry Recognized Mating Diameter | 2.50mm ID (0.098"), 5.50mm OD (0.217") | |
| Actual Diameter | 0.098" (2.50mm ID), 0.224" (5.70mm OD) | |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts | |
| Internal Switch(s) | Single Switch, Normally Closed | |
| Mounting Type | Panel Mount, Through Hole, Right Angle | |
| Mounting Feature | Bulkhead - Front Side Nut | |
| Termination | Solder | |
| Shielding | Unshielded | |
| Features | Mounting Hardware, Thread Lock | |
| Insulation Color | - | |
| Voltage - Rated | 24VDC | |
| Current Rating | 5A | |
| Mating Length/Depth | 0.331" (8.40mm) | |
| Contact Material - Plating | Silver | |
| Body Material | Brass | |
| Operating Temperature | -25°C ~ 70°C | |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer | |
| Standard Package | 500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PJ-066B | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PJ-066B is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of PJ-066B is new and unused, you can buy PJ-066B CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PJ-066B.
