| Manufacturer Part Number: | PFE500S-12 |
|---|---|
| Manufacturer: | TDK-Lambda Americas Inc. |
| Product Category: | AC DC Converters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | AC/DC CONVERTER 12V 33A 500W |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PFE500S-12 Datasheet |
| Internal Part Number | 898-PFE500S-12 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | PFE Series | |
| Featured Product | PFE Series | |
| Category | Power Supplies - Board Mount | |
| Family | AC DC Converters | |
| Manufacturer | TDK-Lambda Americas Inc. | |
| Series | PF | |
| Part Status | Obsolete | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 265 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 33A | |
| Power (Watts) | 500W | |
| Power Supply Type | Switching (Closed Frame) | |
| Applications | ITE (Commercial) | |
| Features | OCP, OTP, OVP | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 82% | |
| Mounting Type | Through Hole | |
| Size / Dimension | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) | |
| Power (Watts) - Max | 396W | |
| Line Regulation | 48mV | |
| Load Regulation | 48mV | |
| Approvals | CE, cULus | |
| Weight | 0.001 KG | |
| Standard Package | 1 | |
| Application | Email for details | |
| Replacement Part | PFE500S-12 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PFE500S-12 is in stock for immediate shipping now. We are the distributor of TDK-Lambda Americas Inc. all series components. The condition of PFE500S-12 is new and unused, you can buy PFE500S-12 TDK-Lambda Americas Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PFE500S-12.
