Manufacturer Part Number: | PF1000A-360 |
---|---|
Manufacturer: | TDK-Lambda Americas Inc. |
Product Category: | AC DC Converters |
Available Quantity: | 9144 Pieces |
Unit Price: | Quote by Email |
Description: | PWR CORRECTI0N MOD 360VDC |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PF1000A-360 Datasheet |
Internal Part Number | 898-PF1000A-360 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | PF Series | |
Category | Power Supplies - Board Mount | |
Family | AC DC Converters | |
Manufacturer | TDK-Lambda Americas Inc. | |
Series | PF | |
Part Status | Active | |
Number of Outputs | 1 | |
Voltage - Input | 85 ~ 265 VAC | |
Voltage - Output 1 | 360V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Voltage - Output 4 | - | |
Current - Output (Max) | 2.8A | |
Power (Watts) | 1000W | |
Power Supply Type | Switching (Closed Frame) | |
Applications | ITE (Commercial) | |
Features | OCP, OTP, OVP | |
Operating Temperature | -40°C ~ 100°C | |
Efficiency | 95% | |
Mounting Type | Through Hole | |
Size / Dimension | 4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm) | |
Power (Watts) - Max | 1008W | |
Line Regulation | 5V | |
Load Regulation | 10V | |
Approvals | CE, cULus | |
Weight | 0.001 KG | |
Standard Package | 1 | |
Application | Email for details | |
Replacement Part | PF1000A-360 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PF1000A-360 is in stock for immediate shipping now. We are the distributor of TDK-Lambda Americas Inc. all series components. The condition of PF1000A-360 is new and unused, you can buy PF1000A-360 TDK-Lambda Americas Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PF1000A-360.
