PEC04DAHN

PEC04DAHN
Manufacturer Part Number:PEC04DAHN
Manufacturer:
Product Category:Rectangular Connectors - Headers, Male Pins
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:8 Positions Header, Unshrouded, Breakaway Connector 0.100" (2.54mm) Through Hole Tin
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: PEC04DAHN Datasheet
PEC04DAHN´s Parameters
Internal Part Number898-PEC04DAHN
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog GxC and PxC
CategoryConnectors, Interconnects
FamilyRectangular Connectors - Headers, Male Pins
ManufacturerSullins Connector Solutions
Series-
PackagingBulk
Part StatusActive
Contact TypeMale Pin
Connector TypeHeader, Unshrouded, Breakaway
Number of Positions8
Number of Positions LoadedAll
Pitch0.100" (2.54mm)
Number of Rows2
Row Spacing0.100" (2.54mm)
Contact Mating Length0.230" (5.84mm)
Mounting TypeThrough Hole
TerminationSolder
Fastening Type-
Features-
Contact FinishTin
Contact Finish Thickness100µin (2.54µm)
ColorBlack
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartPEC04DAHN
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

PEC04DAHN is in stock for immediate shipping now. We are the distributor of Sullins Connector Solutions all series components. The condition of PEC04DAHN is new and unused, you can buy PEC04DAHN Sullins Connector Solutions with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for PEC04DAHN.
