Manufacturer Part Number: | PE-0402HFB182ST |
---|---|
Manufacturer: | Pulse Electronics Corporation |
Product Category: | Ferrite Beads and Chips |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 1.8 kOhm Impedance Ferrite Bead 0402 (1005 Metric) Surface Mount Signal Line 200mA 1 Lines 2 Ohm Max DCR -40°C ~ 105°C |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PE-0402HFB182ST Datasheet |
Internal Part Number | 898-PE-0402HFB182ST | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Featured Product | Ferrite Multi-Layer Beads for EMI Suppression | |
PCN Obsolescence/ EOL | Multipe Devices 21/Jun/2016 | |
Online Catalog | HFB Series | |
Category | Filters | |
Family | Ferrite Beads and Chips | |
Manufacturer | Pulse Electronics Corporation | |
Series | HFB | |
Packaging | Tape & Reel (TR) | |
Part Status | Last Time Buy | |
Filter Type | Signal Line | |
Number of Lines | 1 | |
Impedance @ Frequency | 1.8 kOhm @ 100MHz | |
Current Rating (Max) | 200mA | |
DC Resistance (DCR) (Max) | 2 Ohm | |
Ratings | - | |
Operating Temperature | -40°C ~ 105°C | |
Package / Case | 0402 (1005 Metric) | |
Mounting Type | Surface Mount | |
Height (Max) | 0.026" (0.65mm) | |
Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
Standard Package | 10,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | PE-0402HFB182ST | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PE-0402HFB182ST is in stock for immediate shipping now. We are the distributor of Pulse Electronics Corporation all series components. The condition of PE-0402HFB182ST is new and unused, you can buy PE-0402HFB182ST Pulse Electronics Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PE-0402HFB182ST.
