Manufacturer Part Number: | PDM1-S15-D9-S |
---|---|
Manufacturer: | CUI Inc. |
Product Category: | DC DC Converters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | CONV DC/DC 1W +/-9V 56MA OUT |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | PDM1-S15-D9-S Datasheet |
Internal Part Number | 898-PDM1-S15-D9-S | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Low Power DC-DC Converters EMI Regulations and Mitigation Considerations for Switching Power Supplies Reliability Considerations for Power Supplies Power Supply Safety Standards, Agencies and Marks Thermal Management of Power Supplies | |
RoHS Information | PDM1-S Series Cert of Compliance | |
3D Model | PDM1-S15-D9-S | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | CUI Inc. | |
Series | PDM1-S | |
Packaging | Tube | |
Part Status | Active | |
Type | Isolated Module | |
Number of Outputs | 2 | |
Voltage - Input (Min) | 13.5V | |
Voltage - Input (Max) | 16.5V | |
Voltage - Output 1 | 9V | |
Voltage - Output 2 | -9V | |
Voltage - Output 3 | - | |
Current - Output (Max) | 56mA, 56mA | |
Power (Watts) - Manufacture Series | 1W | |
Voltage - Isolation | 1.5kV (1500V) | |
Applications | ITE (Commercial) | |
Features | SCP | |
Mounting Type | Through Hole | |
Package / Case | 6-DIP Module (5 Leads) | |
Size / Dimension | 0.77" L x 0.24" W x 0.37" H (19.5mm x 6.0mm x 9.3mm) | |
Operating Temperature | -40°C ~ 105°C | |
Efficiency | 80% | |
Power (Watts) - Max | 1W | |
Standard Package | 25 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | PDM1-S15-D9-S | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
PDM1-S15-D9-S is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of PDM1-S15-D9-S is new and unused, you can buy PDM1-S15-D9-S CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PDM1-S15-D9-S.
