| Manufacturer Part Number: | PB-5R0H105-R |
|---|---|
| Manufacturer: | Eaton |
| Product Category: | Electric Double Layer Capacitors, Supercaps |
| Available Quantity: | 9219 Pieces |
| Unit Price: | Quote by Email |
| Description: | 1F Supercap 5V Radial, Can 500 mOhm @ 100Hz 1000 Hrs @ 70°C 0.866" L x 0.681" W (22.00mm x 17.30mm) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PB-5R0H105-R Datasheet |
| Internal Part Number | 898-PB-5R0H105-R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | PowerStor Supercapacitors PowerStor Brand Supercapacitors-Size and Selection | |
| MSDS Material Safety Datasheet | P Series MSDS | |
| PCN Design/Specification | PA,PB,PHB,PHV,PM Series UV Epoxy 01/May/2014 PA,PB,PHB,PHV,PM Series 01/May/2014 | |
| PCN Packaging | B, PB Series Label Color 19/Aug/2013 | |
| Online Catalog | PowerStor, Radial Can Series | |
| Category | Capacitors | |
| Family | Electric Double Layer Capacitors, Supercaps | |
| Manufacturer | Eaton | |
| Series | PowerStor PB | |
| Packaging | Bulk | |
| Part Status | Active | |
| Capacitance | 1F | |
| Tolerance | -20%, +80% | |
| Voltage - Rated | 5V | |
| ESR (Equivalent Series Resistance) | 500 mOhm @ 100Hz | |
| Lifetime @ Temp. | 1000 Hrs @ 70°C | |
| Termination | Through Hole | |
| Mounting Type | Through Hole | |
| Package / Case | Radial, Can | |
| Lead Spacing | 0.465" (11.80mm) | |
| Size / Dimension | 0.866" L x 0.681" W (22.00mm x 17.30mm) | |
| Height - Seated (Max) | 0.354" (9.00mm) | |
| Operating Temperature | -25°C ~ 70°C | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PB-5R0H105-R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PB-5R0H105-R is in stock for immediate shipping now. We are the distributor of Eaton all series components. The condition of PB-5R0H105-R is new and unused, you can buy PB-5R0H105-R Eaton with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PB-5R0H105-R.
