Manufacturer Part Number: | P3519R-155J |
---|---|
Manufacturer: | API Delevan Inc. |
Product Category: | Fixed Inductors |
Available Quantity: | 9110 Pieces |
Unit Price: | Quote by Email |
Description: | 1.5mH Unshielded Wirewound Inductor 95mA 32.75 Ohm Max Nonstandard |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | P3519R-155J Datasheet |
Internal Part Number | 898-P3519R-155J | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | API Delevan Inc. | |
Series | P3519R | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Wirewound | |
Material - Core | Ferrite | |
Inductance | 1.5mH | |
Tolerance | ±5% | |
Current Rating | 95mA | |
Current - Saturation | 110mA | |
Shielding | Unshielded | |
DC Resistance (DCR) | 32.75 Ohm Max | |
Q @ Freq | - | |
Frequency - Self Resonant | - | |
Ratings | - | |
Operating Temperature | -55°C ~ 130°C | |
Frequency - Test | 10kHz | |
Mounting Type | Surface Mount | |
Package / Case | Nonstandard | |
Size / Dimension | 0.358" L x 0.190" W (9.09mm x 4.83mm) | |
Height - Seated (Max) | 0.185" (4.70mm) | |
Standard Package | 100 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | P3519R-155J | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
P3519R-155J is in stock for immediate shipping now. We are the distributor of API Delevan Inc. all series components. The condition of P3519R-155J is new and unused, you can buy P3519R-155J API Delevan Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for P3519R-155J.
