| Manufacturer Part Number: | NX9415CMTR |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | PMIC - Voltage Regulators - DC DC Switching Regulators |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 5A 24-VQFN Exposed Pad |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NX9415CMTR Datasheet |
| Internal Part Number | 898-NX9415CMTR | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Manufacturer | Microsemi Corporation | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 9V | |
| Voltage - Input (Max) | 22V | |
| Voltage - Output (Min/Fixed) | 0.8V | |
| Voltage - Output (Max) | 15.62V | |
| Current - Output | 5A | |
| Frequency - Switching | 200kHz ~ 2.2MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | 0°C ~ 70°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-VQFN Exposed Pad | |
| Supplier Device Package | 24-MCM (4x4) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NX9415CMTR | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NX9415CMTR is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of NX9415CMTR is new and unused, you can buy NX9415CMTR Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NX9415CMTR.
