| Manufacturer Part Number: | NPT42-M |
|---|---|
| Manufacturer: | Artesyn Embedded Technologies |
| Product Category: | AC DC Converters |
| Available Quantity: | 10469 Pieces |
| Unit Price: | Quote by Email |
| Description: | AC/DC CONVERTER 5V +/-12V 45W |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NPT42-M Datasheet |
| Internal Part Number | 898-NPT42-M | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | NPT40-M AC-DC Power Supplies | |
| RoHS Information | Declaration of Conformity | |
| Featured Product | NPT40-M Series | |
| PCN Packaging | CSA Marking 20/Sep/2013 | |
| Online Catalog | NPT40 Series | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Manufacturer | Artesyn Embedded Technologies | |
| Series | NPT40-M | |
| Part Status | Active | |
| Type | Open Frame | |
| Number of Outputs | 3 | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | 12V | |
| Voltage - Output 3 | -12V | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 5A, 2.5A, 500mA | |
| Power (Watts) | 45W (55W Forced Air) | |
| Applications | ITE (Commercial), Medical | |
| Voltage - Isolation | - | |
| Efficiency | 75% | |
| Operating Temperature | 0°C ~ 80°C | |
| Features | DC Input Capable, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 4.00" L x 2.00" W x 1.10" H (101.6mm x 50.8mm x 28.0mm) | |
| Minimum Load Required | Yes | |
| Approvals | CB, CE | |
| Power (Watts) - Max | 45W (55W Forced Air) | |
| Standard Package | 5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NPT42-M | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NPT42-M is in stock for immediate shipping now. We are the distributor of Artesyn Embedded Technologies all series components. The condition of NPT42-M is new and unused, you can buy NPT42-M Artesyn Embedded Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NPT42-M.
