| Manufacturer Part Number: | NFA21SL806X1A48L |
|---|---|
| Manufacturer: | Murata Electronics North America |
| Product Category: | EMI/RFI Filters (LC, RC Networks) |
| Available Quantity: | 13010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LC EMI Filter 2nd Order Low Pass 4 Channel 20mA 0805 (2012 Metric), Array, 10 PC Pad |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NFA21SL806X1A48L Datasheet |
| Internal Part Number | 898-NFA21SL806X1A48L | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | EMIFIL® NFA21 Series | |
| Category | Filters | |
| Family | EMI/RFI Filters (LC, RC Networks) | |
| Manufacturer | Murata Electronics North America | |
| Series | EMIFIL®, NFA21 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Low Pass | |
| Filter Order | 2nd | |
| Technology | LC | |
| Number of Channels | 4 | |
| Center / Cutoff Frequency | 80MHz (Cutoff) | |
| Attenuation Value | 25dB @ 500MHz | |
| Resistance - Channel (Ohms) | - | |
| Current | 20mA | |
| Values | - | |
| ESD Protection | No | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | Data Lines for Mobile Devices | |
| Voltage - Rated | 10V | |
| Mounting Type | Surface Mount | |
| Package / Case | 0805 (2012 Metric), Array, 10 PC Pad | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height | 0.037" (0.95mm) | |
| Standard Package | 4,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NFA21SL806X1A48L | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NFA21SL806X1A48L is in stock for immediate shipping now. We are the distributor of Murata Electronics North America all series components. The condition of NFA21SL806X1A48L is new and unused, you can buy NFA21SL806X1A48L Murata Electronics North America with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NFA21SL806X1A48L.
