| Manufacturer Part Number: | NFA18SL307V1A45L |
|---|---|
| Manufacturer: | Murata Electronics North America |
| Product Category: | EMI/RFI Filters (LC, RC Networks) |
| Available Quantity: | 13010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LC EMI Filter 2nd Order Low Pass 4 Channel 100mA 0603 (1608 Metric), Array, 10 PC Pad |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NFA18SL307V1A45L Datasheet |
| Internal Part Number | 898-NFA18SL307V1A45L | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | EMIFIL® NFA18 Series | |
| Category | Filters | |
| Family | EMI/RFI Filters (LC, RC Networks) | |
| Manufacturer | Murata Electronics North America | |
| Series | EMIFIL®, NFA18 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Low Pass | |
| Filter Order | 2nd | |
| Technology | LC | |
| Number of Channels | 4 | |
| Center / Cutoff Frequency | 300MHz (Cutoff) | |
| Attenuation Value | 20dB @ 900MHz | |
| Resistance - Channel (Ohms) | - | |
| Current | 100mA | |
| Values | - | |
| ESD Protection | No | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Voltage - Rated | 10V | |
| Mounting Type | Surface Mount | |
| Package / Case | 0603 (1608 Metric), Array, 10 PC Pad | |
| Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.80mm) | |
| Height | 0.026" (0.65mm) | |
| Standard Package | 4,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NFA18SL307V1A45L | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NFA18SL307V1A45L is in stock for immediate shipping now. We are the distributor of Murata Electronics North America all series components. The condition of NFA18SL307V1A45L is new and unused, you can buy NFA18SL307V1A45L Murata Electronics North America with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NFA18SL307V1A45L.
