| Manufacturer Part Number: | NDM2Z-50HT-DEMO-ND |
|---|---|
| Manufacturer: | CUI Inc. |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9013 Pieces |
| Unit Price: | Quote by Email |
| Description: | NDM2Z-50 Novum® DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NDM2Z-50HT-DEMO-ND Datasheet |
| Internal Part Number | 898-NDM2Z-50HT-DEMO-ND | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | NDM2Z Series Cert of Compliance | |
| Design Resources | Novum ACE™ Registration | |
| Online Catalog | NDM2Z-50A POL Demo Kit | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | CUI Inc. | |
| Series | Novum® | |
| Part Status | Active | |
| Main Purpose | DC/DC, Step Down | |
| Outputs and Type | 1, Non-Isolated | |
| Power - Output | 165W | |
| Voltage - Output | 1.2V | |
| Current - Output | 50A | |
| Voltage - Input | 4.5 V ~ 14 V | |
| Regulator Topology | Buck | |
| Frequency - Switching | 320kHz | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | NDM2Z-50 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NDM2Z-50HT-DEMO-ND | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NDM2Z-50HT-DEMO-ND is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of NDM2Z-50HT-DEMO-ND is new and unused, you can buy NDM2Z-50HT-DEMO-ND CUI Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NDM2Z-50HT-DEMO-ND.
