Manufacturer Part Number: | NCP45540IMNTWG-H |
---|---|
Manufacturer: | ON Semiconductor |
Product Category: | PMIC - Power Distribution Switches, Load Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC LOAD SWITCH ACT-HI 20A 12DFN |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | NCP45540IMNTWG-H Datasheet |
Internal Part Number | 898-NCP45540IMNTWG-H | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Design/Specification | Lead Finish/BOM Update 10/Jul/2015 | |
Online Catalog | General Purpose | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Power Distribution Switches, Load Drivers | |
Manufacturer | ON Semiconductor | |
Series | ecoSWITCH™ | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Switch Type | General Purpose | |
Number of Outputs | 1 | |
Ratio - Input:Output | 1:1 | |
Output Configuration | High Side | |
Output Type | N-Channel | |
Interface | On/Off | |
Voltage - Load | 0.5 V ~ 13.5 V | |
Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V | |
Current - Output (Max) | 20A | |
Rds On (Typ) | 4.8 mOhm | |
Input Type | Non-Inverting | |
Features | Power Good, Slew Rate Controlled | |
Fault Protection | Over Temperature, UVLO | |
Operating Temperature | -40°C ~ 85°C (TA) | |
Package / Case | 12-VFDFN Exposed Pad | |
Supplier Device Package | 12-DFN (3x3) | |
Standard Package | 3,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | NCP45540IMNTWG-H | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
NCP45540IMNTWG-H is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of NCP45540IMNTWG-H is new and unused, you can buy NCP45540IMNTWG-H ON Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NCP45540IMNTWG-H.
