Manufacturer Part Number: | MZA1210D241C |
---|---|
Manufacturer: | TDK Corporation |
Product Category: | Ferrite Beads and Chips |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 240 Ohm Impedance Ferrite Bead 0504 (1210 Metric), Array, 4 PC Pad Surface Mount Signal Line 50mA 2 Lines 1.2 Ohm Max DCR -55°C ~ 125°C |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MZA1210D241C Datasheet |
Internal Part Number | 898-MZA1210D241C | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Filters | |
Family | Ferrite Beads and Chips | |
Manufacturer | TDK Corporation | |
Series | MZA | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Filter Type | Signal Line | |
Number of Lines | 2 | |
Impedance @ Frequency | 240 Ohm @ 100MHz | |
Current Rating (Max) | 50mA | |
DC Resistance (DCR) (Max) | 1.2 Ohm | |
Ratings | - | |
Operating Temperature | -55°C ~ 125°C | |
Package / Case | 0504 (1210 Metric), Array, 4 PC Pad | |
Mounting Type | Surface Mount | |
Height (Max) | 0.024" (0.60mm) | |
Size / Dimension | 0.049" L x 0.039" W (1.25mm x 1.00mm) | |
Standard Package | 5,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MZA1210D241C | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MZA1210D241C is in stock for immediate shipping now. We are the distributor of TDK Corporation all series components. The condition of MZA1210D241C is new and unused, you can buy MZA1210D241C TDK Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MZA1210D241C.
