| Manufacturer Part Number: | MXSIGDM |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | TX132x,MCP330x,320x,494x,3221,3201,1525,1541 PICtail™ Series Mixed Signal for MCU: ADC, DAC, Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MXSIGDM Datasheet |
| Internal Part Number | 898-MXSIGDM | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | PICtail™ | |
| Part Status | Active | |
| Main Purpose | Mixed Signal for MCU: ADC, DAC, | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | TX132x,MCP330x,320x,494x,3221,3201,1525,1541 | |
| Primary Attributes | 3 ADCs, 3 DACs, 2 Voltage References, 5V LDO | |
| Secondary Attributes | DIP Switches, 2 LEDs, PIC16F767 | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MXSIGDM | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MXSIGDM is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of MXSIGDM is new and unused, you can buy MXSIGDM Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MXSIGDM.
