Manufacturer Part Number: | MPC8560ADS-BGA |
---|---|
Manufacturer: | NXP Semiconductors |
Product Category: | Evaluation Boards - Embedded - MCU, DSP |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | MPC8560 PowerQUICC III™ MPU e500 Embedded Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MPC8560ADS-BGA Datasheet |
Internal Part Number | 898-MPC8560ADS-BGA | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - Embedded - MCU, DSP | |
Manufacturer | Freescale Semiconductor - NXP | |
Series | PowerQUICC III™ | |
Part Status | Obsolete | |
Board Type | Evaluation Platform | |
Type | MPU | |
Core Processor | e500 | |
Operating System | - | |
Platform | - | |
For Use With/Related Products | MPC8560 | |
Mounting Type | Fixed | |
Contents | Board(s) | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MPC8560ADS-BGA | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MPC8560ADS-BGA is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MPC8560ADS-BGA is new and unused, you can buy MPC8560ADS-BGA NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MPC8560ADS-BGA.
