| Manufacturer Part Number: | MP118FD |
|---|---|
| Manufacturer: | Apex Microtechnology |
| Product Category: | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps |
| Available Quantity: | 9067 Pieces |
| Unit Price: | Quote by Email |
| Description: | General Purpose Amplifier 1 Circuit |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MP118FD Datasheet |
| Internal Part Number | 898-MP118FD | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | MP118FD Bandwidth Amplifier | |
| PCN Assembly/Origin | Source Supplier 04/Jan/2016 | |
| Online Catalog | General Purpose | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Manufacturer | Apex Microtechnology | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| Amplifier Type | General Purpose | |
| Number of Circuits | 1 | |
| Output Type | - | |
| Slew Rate | 65 V/µs | |
| Gain Bandwidth Product | 10MHz | |
| -3db Bandwidth | - | |
| Current - Input Bias | 100pA | |
| Voltage - Input Offset | 1mV | |
| Current - Supply | 25mA | |
| Current - Output / Channel | 12A | |
| Voltage - Supply, Single/Dual (±) | ±15 V ~ 100 V | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Through Hole | |
| Package / Case | 34-DIP Module | |
| Supplier Device Package | - | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MP118FD | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MP118FD is in stock for immediate shipping now. We are the distributor of Apex Microtechnology all series components. The condition of MP118FD is new and unused, you can buy MP118FD Apex Microtechnology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MP118FD.
