MP-3501

MP-3501
Manufacturer Part Number:MP-3501
Manufacturer:
Product Category:Barrel - Audio Connectors
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:3.50mm (0.141", 1/8", Mini Plug) - Headphone Phone Plug Mono Connector Solder Eyelet(s)
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):
Production Status (Lifecycle):Obsolete / Discontinued
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: MP-3501 Datasheet
MP-3501´s Parameters
Internal Part Number898-MP-3501
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
CategoryConnectors, Interconnects
FamilyBarrel - Audio Connectors
ManufacturerCUI Inc.
Series-
Packaging-
Part StatusObsolete
Connector TypePhone Plug
GenderMale
Signal LinesMono
Industry Recognized Mating Diameter3.50mm (0.141", 1/8", Mini Plug) - Headphone
Actual Diameter-
Number of Positions/Contacts2 Conductors, 2 Contacts
Internal Switch(s)Does Not Contain Switch
Mounting TypeFree Hanging (In-Line)
TerminationSolder Eyelet(s)
ShieldingUnshielded
FeaturesStrain Relief
Insulation Color-
Voltage - Rated6VDC
Current Rating1A
Mating Length/Depth0.579" (14.70mm)
Contact Material - PlatingNickel
Body Material-
Body ColorBlack
Includes2 pcs - 1 Connector, 1 Handle
Standard Package 100
Weight0.001 KG
ApplicationEmail for details
Replacement PartMP-3501
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

MP-3501 is in stock for immediate shipping now. We are the distributor of CUI Inc. all series components. The condition of MP-3501 is new and unused, you can buy MP-3501 CUI Inc. with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for MP-3501.
