Manufacturer Part Number: | MNG18-156DFIK-A |
---|---|
Manufacturer: | 3M |
Product Category: | Terminals - Barrel, Bullet Connectors |
Available Quantity: | 10242 Pieces |
Unit Price: | Quote by Email |
Description: | Terminal Connector Female, Receptacle (Socket) 18-22 AWG Crimp |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MNG18-156DFIK-A Datasheet |
Internal Part Number | 898-MNG18-156DFIK-A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Video File | Scotchlok Terminals Training | |
Featured Product | Scotchlok™ Tools and Connectors | |
Online Catalog | Scotchlok™ Series | |
Category | Connectors, Interconnects | |
Family | Terminals - Barrel, Bullet Connectors | |
Manufacturer | 3M | |
Series | Scotchlok™ | |
Packaging | Bulk | |
Part Status | Active | |
Terminal Type | Female, Receptacle (Socket) | |
Diameter - Barrel | 0.156" (3.96mm) | |
Wire Gauge | 18-22 AWG | |
Length - Overall | 1.020" (25.91mm) | |
Length - Barrel | 0.250" (6.35mm) | |
Insulation | Fully Insulated | |
Termination | Crimp | |
Features | - | |
Contact Material | - | |
Contact Finish | - | |
Color | Red | |
Insulation Diameter | 0.145" (3.68mm) | |
Material - Insulation | Polyamide (PA), Nylon | |
Standard Package | 1,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MNG18-156DFIK-A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MNG18-156DFIK-A is in stock for immediate shipping now. We are the distributor of 3M all series components. The condition of MNG18-156DFIK-A is new and unused, you can buy MNG18-156DFIK-A 3M with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MNG18-156DFIK-A.
