| Manufacturer Part Number: | MMBZ5223BLT1 |
|---|---|
| Manufacturer: | ON Semiconductor |
| Product Category: | Diodes - Zener - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Zener Diode 2.7V 225mW ±5% Surface Mount SOT-23-3 (TO-236) |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MMBZ5223BLT1 Datasheet |
| Internal Part Number | 898-MMBZ5223BLT1 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 30/Jun/2006 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Manufacturer | ON Semiconductor | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Voltage - Zener (Nom) (Vz) | 2.7V | |
| Tolerance | ±5% | |
| Power - Max | 225mW | |
| Impedance (Max) (Zzt) | 30 Ohm | |
| Current - Reverse Leakage @ Vr | 75µA @ 1V | |
| Voltage - Forward (Vf) (Max) @ If | 900mV @ 10mA | |
| Operating Temperature | -55°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23-3 (TO-236) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MMBZ5223BLT1 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MMBZ5223BLT1 is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of MMBZ5223BLT1 is new and unused, you can buy MMBZ5223BLT1 ON Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MMBZ5223BLT1.
