Manufacturer Part Number: | MLF1005DR15KT |
---|---|
Manufacturer: | TDK Corporation |
Product Category: | Fixed Inductors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 150nH Shielded Multilayer Inductor 25mA 800 mOhm Max 0402 (1005 Metric) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MLF1005DR15KT Datasheet |
Internal Part Number | 898-MLF1005DR15KT | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | SMD Inductors | |
EDA / CAD Models | Download from Accelerated Designs | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | TDK Corporation | |
Series | MLF | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Type | Multilayer | |
Material - Core | Ferrite | |
Inductance | 150nH | |
Tolerance | ±10% | |
Current Rating | 25mA | |
Current - Saturation | - | |
Shielding | Shielded | |
DC Resistance (DCR) | 800 mOhm Max | |
Q @ Freq | 10 @ 25MHz | |
Frequency - Self Resonant | 350MHz | |
Ratings | - | |
Operating Temperature | -40°C ~ 85°C | |
Frequency - Test | 25MHz | |
Mounting Type | Surface Mount | |
Package / Case | 0402 (1005 Metric) | |
Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
Height - Seated (Max) | 0.022" (0.55mm) | |
Standard Package | 10,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MLF1005DR15KT | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MLF1005DR15KT is in stock for immediate shipping now. We are the distributor of TDK Corporation all series components. The condition of MLF1005DR15KT is new and unused, you can buy MLF1005DR15KT TDK Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MLF1005DR15KT.
