Manufacturer Part Number: | MKW21D256VHA5R |
---|---|
Manufacturer: | NXP Semiconductors |
Product Category: | RF Transceiver ICs |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC RF TxRx + MCU 802.15.4 Zigbee® 2.4GHz 63-VFLGA |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MKW21D256VHA5R Datasheet |
Internal Part Number | 898-MKW21D256VHA5R | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector IoT Product Selector | |
PCN Design/Specification | Copper Wire Conversion 27/May/2015 MKW2xD 14/Jun/2016 | |
Category | RF/IF and RFID | |
Family | RF Transceiver ICs | |
Manufacturer | Freescale Semiconductor - NXP | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | TxRx + MCU | |
RF Family/Standard | 802.15.4 | |
Protocol | Zigbee® | |
Modulation | DSSS, O-QPSK | |
Frequency | 2.4GHz | |
Data Rate (Max) | 250kbps | |
Power - Output | 8dBm | |
Sensitivity | -102dBm | |
Memory Size | 256kB Flash, 32kB SRAM | |
Serial Interfaces | I²C, JTAG, SPI, UART | |
GPIO | 2 | |
Voltage - Supply | 1.8 V ~ 3.6 V | |
Current - Receiving | 15mA | |
Current - Transmitting | 19mA | |
Operating Temperature | -40°C ~ 105°C | |
Package / Case | 63-VFLGA | |
Standard Package | 2,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MKW21D256VHA5R | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MKW21D256VHA5R is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MKW21D256VHA5R is new and unused, you can buy MKW21D256VHA5R NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MKW21D256VHA5R.
