Manufacturer Part Number: | MIC2206-1.8YML-EV |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9012 Pieces |
Unit Price: | Quote by Email |
Description: | MIC2206 - DC/DC, Step Down with LDO 1, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MIC2206-1.8YML-EV Datasheet |
Internal Part Number | 898-MIC2206-1.8YML-EV | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector | |
Online Catalog | MIC2206 Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Discontinued | |
Main Purpose | DC/DC, Step Down with LDO | |
Outputs and Type | 1, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 1V or 1.8V | |
Current - Output | 600mA | |
Voltage - Input | 2.7 V ~ 5.5 V | |
Regulator Topology | Buck | |
Frequency - Switching | 2MHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | MIC2206 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MIC2206-1.8YML-EV | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MIC2206-1.8YML-EV is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of MIC2206-1.8YML-EV is new and unused, you can buy MIC2206-1.8YML-EV Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MIC2206-1.8YML-EV.
