| Manufacturer Part Number: | MDL-S2E |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LM3S6432 - Interface, Ethernet Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MDL-S2E Datasheet |
| Internal Part Number | 898-MDL-S2E | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Texas Instruments | |
| Series | - | |
| Part Status | Obsolete | |
| Main Purpose | Interface, Ethernet | |
| Embedded | Yes, MCU, 32-Bit | |
| Utilized IC / Part | LM3S6432 | |
| Primary Attributes | Serial-to-Ethernet, 230.4 kBaud, 10/100 Mbit Ethernet Port | |
| Secondary Attributes | Ready-for-Production, Auto MDI/MDIX Correction | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MDL-S2E | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MDL-S2E is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of MDL-S2E is new and unused, you can buy MDL-S2E Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MDL-S2E.
