MDF6-14DP-3.5DSA(05)

MDF6-14DP-3.5DSA(05)
Manufacturer Part Number:MDF6-14DP-3.5DSA(05)
Manufacturer:
Product Category:Rectangular Connectors - Headers, Male Pins
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:14 Positions Header, Shrouded Connector 0.138" (3.50mm) Through Hole Tin
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: MDF6-14DP-3.5DSA(05) Datasheet
MDF6-14DP-3.5DSA(05)´s Parameters
Category
Internal Part Number898-MDF6-14DP-3.5DSA(05)
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
  • H124169-ND
  • Hirose Electric Co Ltd
  • CONN RCPT 14POS 3.5MMUnit Price0.52000
  • Connectors, Interconnects
    FamilyRectangular Connectors - Headers, Male Pins
    ManufacturerHirose Electric Co Ltd
    SeriesMDF6
    PackagingBulk
    Part StatusActive
    Contact TypeMale Pin
    Connector TypeHeader, Shrouded
    Number of Positions14
    Number of Positions LoadedAll
    Pitch0.138" (3.50mm)
    Number of Rows2
    Row Spacing0.197" (5.00mm)
    Contact Mating Length0.220" (5.59mm)
    Mounting TypeThrough Hole
    TerminationSolder
    Fastening TypeLatch Holder
    Features-
    Contact FinishTin
    Contact Finish Thickness-
    ColorWhite
    Standard Package 100
    Weight0.001 KG
    ApplicationEmail for details
    Replacement PartMDF6-14DP-3.5DSA(05)
    Country of OriginUSA / JAPAN / Philippines / Malaysia
    MOQ1 Piece
    Picture / Image / PhotoSend via email

    MDF6-14DP-3.5DSA(05) is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of MDF6-14DP-3.5DSA(05) is new and unused, you can buy MDF6-14DP-3.5DSA(05) Hirose Electric Co Ltd with us at a very low price and quick delivery.

    Please kindly send us an email if you have any demands for MDF6-14DP-3.5DSA(05).
