| Manufacturer Part Number: | MCP7382XEV |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MCP73826, MCP73827, MCP73828 - Power Management, Battery Charger Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MCP7382XEV Datasheet |
| Internal Part Number | 898-MCP7382XEV | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | MCP7382x Eval Brd Gerber Files Development Tool Selector | |
| Reference Design Library | MCP7382XEV: Li-Ion Li-Pol, Battery Charger | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Power Management, Battery Charger | |
| Embedded | No | |
| Utilized IC / Part | MCP73826, MCP73827, MCP73828 | |
| Primary Attributes | 1 Cell- Li-Ion / Li-Pol, 4.2V @ 1A, 4.5 ~ 6V in | |
| Secondary Attributes | - | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MCP7382XEV | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MCP7382XEV is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of MCP7382XEV is new and unused, you can buy MCP7382XEV Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCP7382XEV.
