Manufacturer Part Number: | MCP1650DM-LED2 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - LED Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | MCP1650 1, Non-Isolated Output LED Driver Evaluation Board |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MCP1650DM-LED2 Datasheet |
Internal Part Number | 898-MCP1650DM-LED2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector Lighting Product Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - LED Drivers | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Obsolete | |
Current - Output / Channel | 15mA | |
Outputs and Type | 1, Non-Isolated | |
Voltage - Output | 32.4V | |
Features | Dimmable | |
Voltage - Input | 2.7 V ~ 4.5 V | |
Supplied Contents | Board | |
Utilized IC / Part | MCP1650 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MCP1650DM-LED2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MCP1650DM-LED2 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of MCP1650DM-LED2 is new and unused, you can buy MCP1650DM-LED2 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCP1650DM-LED2.
