Manufacturer Part Number: | MCP1612EV |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9012 Pieces |
Unit Price: | Quote by Email |
Description: | MCP1612 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MCP1612EV Datasheet |
Internal Part Number | 898-MCP1612EV | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Mfg Application Notes | MCP1612 Application Note AN968 | |
Design Resources | MCP1612EV Gerber Files Development Tool Selector | |
Reference Design Library | MCP1612EV: Selectable Voltage: 0.8 ~ Vin MCP1612EV: 0.8V, 1V, 1.2V, 1.4V @1A; 2.7 ~ 5.5V in | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | DC/DC, Step Down | |
Outputs and Type | 1, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 0.8V, 1V, 1.2V, 1.4V, 1.7V, 2.4V or 3.3V | |
Current - Output | 1A | |
Voltage - Input | 2.7 V ~ 5.5 V | |
Regulator Topology | Buck | |
Frequency - Switching | 1.4MHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | MCP1612 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MCP1612EV | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MCP1612EV is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of MCP1612EV is new and unused, you can buy MCP1612EV Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCP1612EV.
