| Manufacturer Part Number: | MCIMX6Q-SDB |
|---|---|
| Manufacturer: | NXP Semiconductors |
| Product Category: | Evaluation Boards - Embedded - MCU, DSP |
| Available Quantity: | 9058 Pieces |
| Unit Price: | Quote by Email |
| Description: | i.MX 6Quad SABRE i.MX MPU ARM® Cortex®-A9 Embedded Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MCIMX6Q-SDB Datasheet |
| Internal Part Number | 898-MCIMX6Q-SDB | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | i.MX 6 Series Applications Processors Introduction | |
| Design Resources | Linux MCIMX6Q-SDB Quick Start Development Tool Selector | |
| Featured Product | WiLink™ Solutions i.MX6 Series Processors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | i.MX 6Quad Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - Embedded - MCU, DSP | |
| Manufacturer | Freescale Semiconductor - NXP | |
| Series | i.MX | |
| Part Status | Active | |
| Board Type | Evaluation Platform | |
| Type | MPU | |
| Core Processor | ARM® Cortex®-A9 | |
| Operating System | - | |
| Platform | SABRE | |
| For Use With/Related Products | i.MX 6Quad | |
| Mounting Type | Fixed | |
| Contents | Board(s) | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MCIMX6Q-SDB | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MCIMX6Q-SDB is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MCIMX6Q-SDB is new and unused, you can buy MCIMX6Q-SDB NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCIMX6Q-SDB.
