| Manufacturer Part Number: | MCF52233CVM60 |
|---|---|
| Manufacturer: | NXP Semiconductors |
| Product Category: | Embedded - Microcontrollers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Coldfire V2 MCF5223x Microcontroller IC 32-Bit 60MHz 256KB (256K x 8) FLASH 121-MAPBGA (12x12) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MCF52233CVM60 Datasheet |
| Internal Part Number | 898-MCF52233CVM60 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Oct/2012 | |
| PCN Design/Specification | Copper Wire Conversion 20/May/2014 Errata Update 16/Feb/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Manufacturer | Freescale Semiconductor - NXP | |
| Series | MCF5223x | |
| Packaging | Tray | |
| Part Status | Active | |
| Core Processor | Coldfire V2 | |
| Core Size | 32-Bit | |
| Speed | 60MHz | |
| Connectivity | Ethernet, I²C, SPI, UART/USART | |
| Peripherals | DMA, LVD, POR, PWM, WDT | |
| Number of I/O | 73 | |
| Program Memory Size | 256KB (256K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 32K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 3.6 V | |
| Data Converters | A/D 8x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 121-LBGA | |
| Supplier Device Package | 121-MAPBGA (12x12) | |
| Standard Package | 189 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MCF52233CVM60 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MCF52233CVM60 is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MCF52233CVM60 is new and unused, you can buy MCF52233CVM60 NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCF52233CVM60.
