| Manufacturer Part Number: | MCF-25JR-56R |
|---|---|
| Manufacturer: | Yageo |
| Product Category: | Chip Resistor - Surface Mount |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RES SMD 56 OHM 5% 1/4W MELF |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MCF-25JR-56R Datasheet |
| Internal Part Number | 898-MCF-25JR-56R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Manufacturer | Yageo | |
| Series | MCF | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Resistance (Ohms) | 56 | |
| Tolerance | ±5% | |
| Power (Watts) | 0.25W, 1/4W | |
| Composition | Carbon Film | |
| Features | - | |
| Temperature Coefficient | 0/ -350ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | MELF, 0207 | |
| Supplier Device Package | MELF | |
| Size / Dimension | 0.087" Dia x 0.232" L (2.20mm x 5.90mm) | |
| Height | - | |
| Number of Terminations | 2 | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MCF-25JR-56R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MCF-25JR-56R is in stock for immediate shipping now. We are the distributor of Yageo all series components. The condition of MCF-25JR-56R is new and unused, you can buy MCF-25JR-56R Yageo with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCF-25JR-56R.
