Manufacturer Part Number: | MC33580BAPNAR2 |
---|---|
Manufacturer: | NXP Semiconductors |
Product Category: | PMIC - Power Distribution Switches, Load Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC SW QUAD HI SIDE 15MOHM 24PQFN |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MC33580BAPNAR2 Datasheet |
Internal Part Number | 898-MC33580BAPNAR2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
EDA / CAD Models | Download from Accelerated Designs | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Power Distribution Switches, Load Drivers | |
Manufacturer | Freescale Semiconductor - NXP | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Switch Type | General Purpose | |
Number of Outputs | 4 | |
Ratio - Input:Output | 1:1 | |
Output Configuration | High Side | |
Output Type | N-Channel | |
Interface | SPI | |
Voltage - Load | 6 V ~ 27 V | |
Voltage - Supply (Vcc/Vdd) | 4.5 V ~ 5.5 V | |
Current - Output (Max) | - | |
Rds On (Typ) | 15 mOhm | |
Input Type | - | |
Features | Slew Rate Controlled, Watchdog Timer | |
Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage | |
Operating Temperature | -40°C ~ 150°C (TJ) | |
Package / Case | 24-PowerQFN | |
Supplier Device Package | 24-PQFN (12x12) | |
Standard Package | 1,200 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MC33580BAPNAR2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MC33580BAPNAR2 is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MC33580BAPNAR2 is new and unused, you can buy MC33580BAPNAR2 NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MC33580BAPNAR2.
