Manufacturer Part Number: | MC10XS4200FK |
---|---|
Manufacturer: | NXP Semiconductors |
Product Category: | PMIC - Power Distribution Switches, Load Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC SW HIGH SIDE 24V DUAL 23PQFN |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MC10XS4200FK Datasheet |
Internal Part Number | 898-MC10XS4200FK | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Design/Specification | Copper Wire Update 05/Jun/2015 | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Power Distribution Switches, Load Drivers | |
Manufacturer | Freescale Semiconductor - NXP | |
Series | - | |
Packaging | Tray | |
Part Status | Active | |
Switch Type | General Purpose | |
Number of Outputs | 2 | |
Ratio - Input:Output | 1:1 | |
Output Configuration | High Side | |
Output Type | N-Channel | |
Interface | SPI | |
Voltage - Load | 8 V ~ 36 V | |
Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V | |
Current - Output (Max) | 6A | |
Rds On (Typ) | 10 mOhm (Max) | |
Input Type | - | |
Features | Internal PWM, Slew Rate Controlled, Watchdog Timer | |
Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO | |
Operating Temperature | -40°C ~ 125°C (TA) | |
Package / Case | 23-PowerQFN | |
Supplier Device Package | 23-PQFN (12x12) | |
Standard Package | 840 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MC10XS4200FK | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MC10XS4200FK is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MC10XS4200FK is new and unused, you can buy MC10XS4200FK NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MC10XS4200FK.
