Manufacturer Part Number: | MBRP400100CTL |
---|---|
Manufacturer: | ON Semiconductor |
Product Category: | Diodes - Rectifiers - Arrays |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Diode Array 1 Pair Common Cathode Schottky 100V 200A Chassis Mount Powertap II |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MBRP400100CTL Datasheet |
Internal Part Number | 898-MBRP400100CTL | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Obsolescence/ EOL | Multiple Devices 15/May/2006 | |
Category | Discrete Semiconductor Products | |
Family | Diodes - Rectifiers - Arrays | |
Manufacturer | ON Semiconductor | |
Series | SWITCHMODE™ | |
Packaging | Tray | |
Part Status | Obsolete | |
Diode Configuration | 1 Pair Common Cathode | |
Diode Type | Schottky | |
Voltage - DC Reverse (Vr) (Max) | 100V | |
Current - Average Rectified (Io) (per Diode) | 200A | |
Voltage - Forward (Vf) (Max) @ If | 830mV @ 200A | |
Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
Reverse Recovery Time (trr) | - | |
Current - Reverse Leakage @ Vr | 6mA @ 100V | |
Mounting Type | Chassis Mount | |
Package / Case | Powertap II | |
Supplier Device Package | PowerTap II | |
Standard Package | 25 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MBRP400100CTL | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MBRP400100CTL is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of MBRP400100CTL is new and unused, you can buy MBRP400100CTL ON Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MBRP400100CTL.
