| Manufacturer Part Number: | M701-340542 |
|---|---|
| Manufacturer: | Harwin Inc. |
| Product Category: | USB, DVI, HDMI Connectors |
| Available Quantity: | 9642 Pieces |
| Unit Price: | Quote by Email |
| Description: | USB - mini B USB 2.0 Receptacle Connector 5 Position Surface Mount, Right Angle, Horizontal |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | M701-340542 Datasheet |
| Internal Part Number | 898-M701-340542 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | Harwin Inc – USB | |
| Category | Connectors, Interconnects | |
| Family | USB, DVI, HDMI Connectors | |
| Manufacturer | Harwin Inc. | |
| Series | M701 | |
| Packaging | Bulk | |
| Part Status | Active | |
| Connector Type | USB - mini B | |
| Number of Contacts | 5 | |
| Gender | Receptacle | |
| Specifications | USB 2.0 | |
| Mounting Type | Surface Mount, Right Angle, Horizontal | |
| Features | Solder Retention | |
| Ingress Protection | - | |
| Standard Package | 68 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | M701-340542 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
M701-340542 is in stock for immediate shipping now. We are the distributor of Harwin Inc. all series components. The condition of M701-340542 is new and unused, you can buy M701-340542 Harwin Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for M701-340542.
