| Manufacturer Part Number: | M232110-1K |
|---|---|
| Manufacturer: | Ethertronics Inc. |
| Product Category: | RF Antennas |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 1.575GHz, 2.4GHz Bluetooth, GPS Chip RF Antenna 1.575GHz, 2.4GHz ~ 2.5GHz 1.98dBi, 1.88dBi Solder Surface Mount |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | M232110-1K Datasheet |
| Internal Part Number | 898-M232110-1K | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| PCN Part Status Change | Antenna Color Chg 23/May/2016 | |
| Category | RF/IF and RFID | |
| Family | RF Antennas | |
| Manufacturer | Ethertronics Inc. | |
| Series | Savvi™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Frequency Group | UHF (1 GHz ~ 2 GHz), UHF (2 GHz ~ 3 GHz) | |
| Frequency (Center/Band) | 1.575GHz, 2.4GHz | |
| Frequency Range | 1.575GHz, 2.4GHz ~ 2.5GHz | |
| Antenna Type | Chip | |
| Number of Bands | 2 | |
| VSWR | 2, 2.6 | |
| Return Loss | - | |
| Gain | 1.98dBi, 1.88dBi | |
| Power - Max | 500mW | |
| Features | - | |
| Termination | Solder | |
| Ingress Protection | - | |
| Mounting Type | Surface Mount | |
| Height (Max) | 0.051" (1.30mm) | |
| Applications | Bluetooth, GPS | |
| Standard Package | 1,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | M232110-1K | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
M232110-1K is in stock for immediate shipping now. We are the distributor of Ethertronics Inc. all series components. The condition of M232110-1K is new and unused, you can buy M232110-1K Ethertronics Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for M232110-1K.
