Manufacturer Part Number: | M22-6033042 |
---|---|
Manufacturer: | Harwin Inc. |
Product Category: | Backplane Connectors - Specialized |
Available Quantity: | 9223 Pieces |
Unit Price: | Quote by Email |
Description: | PC104 PLUS HEADER RECEPTACLE |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | M22-6033042 Datasheet |
Internal Part Number | 898-M22-6033042 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | M20, M22 Series | |
Category | Connectors, Interconnects | |
Family | Backplane Connectors - Specialized | |
Manufacturer | Harwin Inc. | |
Series | M22 | |
Packaging | Tube | |
Part Status | Active | |
Connector Usage | - | |
Connector Type | Header, Female Sockets | |
Connector Style | PC/104 Plus | |
Number of Positions | 120 | |
Number of Positions Loaded | All | |
Pitch | 0.079" (2.00mm) | |
Number of Rows | 4 | |
Number of Columns | - | |
Mounting Type | Through Hole | |
Termination | Solder | |
Contact Layout, Typical | - | |
Features | - | |
Contact Finish | Gold | |
Contact Finish Thickness | - | |
Color | Black | |
Current Rating | 1A | |
Material Flammability Rating | - | |
Operating Temperature | -55°C ~ 105°C | |
Voltage Rating | - | |
Standard Package | 9 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | M22-6033042 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
M22-6033042 is in stock for immediate shipping now. We are the distributor of Harwin Inc. all series components. The condition of M22-6033042 is new and unused, you can buy M22-6033042 Harwin Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for M22-6033042.
