Manufacturer Part Number: | LZ1-00DB00-0000 |
---|---|
Manufacturer: | LED Engin Inc. |
Product Category: | LED Lighting - Color |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | LED Lighting Color - Blue 460nm (457nm ~ 463nm) 4-SMD, No Lead Exposed Pad |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LZ1-00DB00-0000 Datasheet |
Internal Part Number | 898-LZ1-00DB00-0000 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Lighting Product Selector | |
Online Catalog | LZ Series | |
Category | Optoelectronics | |
Family | LED Lighting - Color | |
Manufacturer | LED Engin Inc. | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Color | Blue | |
Wavelength | 460nm (457nm ~ 463nm) | |
Current - Test | 1A | |
Voltage - Forward (Vf) (Typ) | 3.6V | |
Lumens/Watt @ Current - Test | - | |
Current - Max | 1.2A | |
Flux @ Current/Temperature - Test | 1025mW (800mW ~ 1250mW) | |
Temperature - Test | 25°C | |
Viewing Angle | 80° | |
Mounting Type | Surface Mount | |
Package / Case | 4-SMD, No Lead Exposed Pad | |
Thermal Resistance of Package | 4.2°C/W | |
Standard Package | 100 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LZ1-00DB00-0000 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LZ1-00DB00-0000 is in stock for immediate shipping now. We are the distributor of LED Engin Inc. all series components. The condition of LZ1-00DB00-0000 is new and unused, you can buy LZ1-00DB00-0000 LED Engin Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LZ1-00DB00-0000.
