| Manufacturer Part Number: | LXM1615-03-02 |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Inverters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | CCFL and UV Lamps Inverter 3.3V Input 1800V Output 3.70" L x 0.59" W x 0.18" H (94mm x 15mm x 4.6mm) Chassis Mount |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LXM1615-03-02 Datasheet |
| Internal Part Number | 898-LXM1615-03-02 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Optoelectronics | |
| Family | Inverters | |
| Manufacturer | Microsemi Corporation | |
| Series | LXM1615-03-xx | |
| Part Status | Obsolete | |
| Voltage - Input | 3.3V | |
| Output | 1800V | |
| Type | CCFL and UV Lamps | |
| Size / Dimension | 3.70" L x 0.59" W x 0.18" H (94mm x 15mm x 4.6mm) | |
| Mounting Type | Chassis Mount | |
| Standard Package | 150 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LXM1615-03-02 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LXM1615-03-02 is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of LXM1615-03-02 is new and unused, you can buy LXM1615-03-02 Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LXM1615-03-02.
