| Manufacturer Part Number: | LTPL-M03622ZS50-F1 |
|---|---|
| Manufacturer: | Lite-On Inc. |
| Product Category: | LED Lighting - COBs, Engines, Modules |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LED Lighting COBs, Engines, Modules Chip On Board (COB) LTPL-M03 White, Cool Square |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LTPL-M03622ZS50-F1 Datasheet |
| Internal Part Number | 898-LTPL-M03622ZS50-F1 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Online Catalog | LTPL-M03 Series | |
| Category | Optoelectronics | |
| Family | LED Lighting - COBs, Engines, Modules | |
| Manufacturer | Lite-On Inc. | |
| Series | LTPL-M03 | |
| Packaging | Tray | |
| Part Status | Active | |
| Type | Chip On Board (COB) | |
| Color | White, Cool | |
| CCT (K) | 5000K 5-Step MacAdam Ellipse | |
| Wavelength | - | |
| Configuration | Square | |
| Flux @ Current/Temperature - Test | 2541 lm (Typ) | |
| Current - Test | 500mA | |
| Temperature - Test | 25°C | |
| Voltage - Forward (Vf) (Typ) | 38.3V | |
| Lumens/Watt @ Current - Test | 133 lm/W | |
| Current - Max | 600mA | |
| CRI (Color Rendering Index) | 80 | |
| Viewing Angle | 120° | |
| Features | - | |
| Size / Dimension | 15.85mm L x 15.85mm W | |
| Height | 1.60mm | |
| Light Emitting Surface (LES) | 8.90mm Diameter | |
| Lens Type | Flat | |
| Standard Package | 10 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LTPL-M03622ZS50-F1 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LTPL-M03622ZS50-F1 is in stock for immediate shipping now. We are the distributor of Lite-On Inc. all series components. The condition of LTPL-M03622ZS50-F1 is new and unused, you can buy LTPL-M03622ZS50-F1 Lite-On Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LTPL-M03622ZS50-F1.
