| Manufacturer Part Number: | LT3597IUHG#TRPBF |
|---|---|
| Manufacturer: | Linear Technology |
| Product Category: | PMIC - LED Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LED Driver IC 3 Output DC DC Regulator Step-Down (Buck) PWM Dimming 100mA 52-QFN (5x8) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LT3597IUHG#TRPBF Datasheet |
| Internal Part Number | 898-LT3597IUHG#TRPBF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Reference Design Library | DC1497A: 100mA @ 38V Max, 6 ~ 55V in, Buck | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Manufacturer | Linear Technology | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | DC DC Regulator | |
| Topology | Step-Down (Buck) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 3 | |
| Voltage - Supply (Min) | 6V | |
| Voltage - Supply (Max) | 55V | |
| Voltage - Output | - | |
| Current - Output / Channel | 100mA | |
| Frequency | 200kHz ~ 1MHz | |
| Dimming | PWM | |
| Applications | Backlight | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 52-WFQFN (39 Leads) Exposed Pad | |
| Supplier Device Package | 52-QFN (5x8) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LT3597IUHG#TRPBF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LT3597IUHG#TRPBF is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of LT3597IUHG#TRPBF is new and unused, you can buy LT3597IUHG#TRPBF Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LT3597IUHG#TRPBF.
