Manufacturer Part Number: | LMZ31506RUQT |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | DC DC Converters |
Available Quantity: | 10010 Pieces |
Unit Price: | Quote by Email |
Description: | DC/DC CONVERTER 0.6-5.5V 33W |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LMZ31506RUQT Datasheet |
Internal Part Number | 898-LMZ31506RUQT | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Powering FPGAs with SIMPLE SWITCHER® LMZ3 Power Modules SIMPLE SWITCHER® DC-DC Regulator and Module Portfolio Overview Power SIMPLE SWITCHER Nano Modules Overview | |
Video File | Wide VIN Power Design with LMZ3 SIMPLE SWITCHER Power Module SIMPLE SWITCHER® Power Modules with High Power Density SIMPLE SWITCHER Synchronous Regulator Family Overview The Most Interesting Engineer in the World Layout Tips for Radiated EMI Reduction in Your Designs Thermal Design Made Simple Loop Compensation Made SIMPLE WEBENCH PCB Export for Synchronous SIMPLE SWITCHER Devices | |
Design Resources | LMZ31506 Design with WEBENCH® Power Designer | |
Featured Product | Analog Solutions for Xilinx FPGAs and CPLDs – Texas Instruments | DigiKey | |
PCN Assembly/Origin | Assembly/Test Site Qualification 24/Sep/2014 | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | SIMPLE SWITCHER® LMZ31506 Power Modules Series | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | Texas Instruments | |
Series | SIMPLE SWITCHER® | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Non-Isolated PoL Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 1.6V | |
Voltage - Input (Max) | 14.5V | |
Voltage - Output 1 | 0.6 ~ 5.5 V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 6A | |
Power (Watts) - Manufacture Series | - | |
Voltage - Isolation | - | |
Applications | ITE (Commercial) | |
Features | OCP, OTP, UVLO | |
Mounting Type | Surface Mount | |
Package / Case | 47-QFN | |
Size / Dimension | 0.59" L x 0.35" W x 0.11" H (15.0mm x 9.0mm x 2.8mm) | |
Operating Temperature | -40°C ~ 85°C | |
Efficiency | 95% | |
Power (Watts) - Max | 33W | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LMZ31506RUQT | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LMZ31506RUQT is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LMZ31506RUQT is new and unused, you can buy LMZ31506RUQT Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LMZ31506RUQT.
